3 Ports Optical Circulator

Optical Path:
Port 1 to Port 2
Port 2 to Port 3
HyOptic Optical Circulator     circulator specification
    HyOptic 3 Ports Polarization Insensitive Optical Circulator is passive optical component designed for routing light path, while input signal from port 1, then signal will transmit forward next port and output from port 2.
    3 Ports Polarization Insensitive Optical Circulator
    Parameters Unit Limited Value
    Insertion Ioss dB ≤0.8
    PDL(Polarization Dependent Loss) dB ≤0.1
    Return Loss dB ≥45
    Directivity dB ≥55
    File Name : Format: Size: Download:
    Contact us for details!

    *

    *

    *

    *
